Mô tả
5MP SONY Starvis back-illuminated CMOS sensor.
Smart IR, combines high and low beams to adjust intensity for different lighting conditions.
Support H.264 / H.264+ / H.265 (HEVC) / H.265+ / MJPEG compression format.
Support 120dB HDR, 3DNR, BLC, AWB, Defog technology to restore clear images in foggy days.
Support 30fps high frame rate, easy to capture images without lag in high-speed motion.
Support Micro SD/SDHC/SDXC card storage up to 1TB.
Support API / ONVIF (G/Q/S/T) protocol.
Built-in multiple intelligent analysis functions.
Support RJ45 10/100M, built-in POE 802.3af network power supply.
Support mobile monitoring (iPhone / iPad / Android / Android Pad).
Support various browsers (IE8~11 / Chrome / Firefox / Safari) and client software (VMS).
SIP (Session Initiation Protocol) provides audio/alarm/intercom & video streaming for mobile & video telephony.
IK10 vandal-proof & IP67 weatherproof housing.
Enable Smart Stream to save bandwidth, storage space and bit rate (ex: H.265+ saves 70%~80% bandwidth compared to H.264)
Support NAS (NFS/SMB/CIFS) network storage.
Support ANR (Automatic Network Replenishment) for replenishing the recordings gap due to internet interruptions.
The adjustable 3-axis bracket provides a sturdy mounting platform for angle adjustments in the 3-axis plane.
Specifications:
Model No. NS5DPR
CMOS Image Sensor 1/2.8″ 5MP SONY Starvis Back Illuminated CMOS Sensor
Effective Pixels (HxV) 2592×1944
Compression Format H.264 / H.264+ / H.265 (HEVC) / H.265+ / MJPEG
Video Format Standard NTSC / PAL
Elec. Shutter Speed 1/100,000s
Minimum Illumination 0.008 LUX @F2.0 / 0 LUX @ IR
S/N Ratio ≥ 55 dB
Wide Dynamic Range 120dB
System Scan Progressive
Video Output Network
Lens Furnished HD Board Lens Fixed Focal 1.68mm / F2.0
Angle of View H: 180° / V: 95°
Day & Night Day / Night / Auto / Custom / Schedule
IR Projection Distance Up to 15M
Main Stream 60Hz: 30fps@2144×2144 / 2048×2048 / 1920×1920 / 1280×1280
50Hz: 25fps@2144×2144 / 2048×2048 / 1920×1920 / 1280×1280
Sub Stream 60Hz: 30fps@1280×1280 / 1024×1024 / 736×736 / 576×576
50Hz: 25fps@1280×1280 / 1024×1024 / 736×736 / 576×576
3rd Sstream
60Hz: 30fps@1280×720 / 704×576 / 640×480 / 640×360 / 352×288 / 320×240
50Hz: 25fps@1280×720 / 704×576 / 640×480 / 640×360 / 352×288 / 320×240
Video Bit Rate 16Kbps~16Mbps (CBR/VBR adjustable)
Image Mask Up to 8 areas
ROI (Region of Interest) Up to 8 zones
Image Configuration Brightness / Contrast / Saturation / Sharpness
Ethernet 1*RJ-45 10/100M
Network Storage NAS (Supports NFS, SMB / CIFS) / Internet-disconnected Smart Recording (ANR)
Network Protocol IPv4/IPv6 / ARP / TCP / UDP / RTCP / RTP / RTSP / RTMP / HTTP / HTTPS / DNS / DDNS / DHCP / FTP / NTP / SMTP / SNMP / UpnP / Bonjour / SIP / PPPoE / VLAN / 802.1x / QoS / IGMP / CMP / SSL
Intelligent Analysis Region Entrance / Region Exiting / Advanced Motion Detection / Tamper Detection / Line Crossing / Loitering / Object Left / Object Removed
People Counting & Report Count the number of people entering and exiting, up to 4 detection areas for regional people counting
Advanced Functions Heat Map / BLC / HLC / 2D DNR / 3D DNR / Defog / AWB / EIS / IP Address Filtering / AGC / Anti-Flicker / Corridor Mode / Deblur / Watermark
SIP/VoIP Support
Audio Input: 1CH / Output: 1CH
Audio Compression G711/AAC/G722/G726
Audio Sample Rate 8/16/32/44.1/48KHz
Voice Intercom Support
Memory Card Slot Support Micro SD / SDHC / SDXC Card Local Storage (Up to 1TB)
Event Trigger Motion Detection / Network Disconnection, etc.
Event Action FTP Upload / SMTP Upload / SD Card Recording / External Output / SIP Phone / HTTP Notification, etc.
Housing Material Metal IK10 Vandal-proof & IP67 Weatherproof
Operating Environment Temperature: -10°C to 50°C (14°F to 122°F)
Humidity: 90% Non-condensing
Protocol API / ONVIF Profile (G/Q/S/T)
Power Supply DC12V±10%, Built-in POE, Support 802.3af
Power Consumption Max. 6W / 9W (IR On)
P2P Support
Dimensions 127.2(D) x 107(H) mm
Weight 853g
