CAMERA
Image Sensor
1 / 2.9 ” CMOS
Image Size
1920 × 1080
Electronic Shutter
1 / 25 s ~ 1 / 100000 s
Min. Illumination
0.0035 lux @ F1.2, AGC ON; 0 lux with IR
Lens
Board 2.8 mm @F2.0
Horizontal view Angle
107° IR Distance
20 ~ 30 m
WDR
Digital WDR
Day & Night
ICR auto switch
BLC
YES
HLC
YES
Defog
YES
Digital NVR
3D DNR
Angle Adjustment
Pan: 0°~360°; Tilt:0°~75°; Rotation: 0°~360°
· IMAGE
Video Compression
H.265 / H.264 / MJPEG
H.265 Compression Standard
Main Profile@ Leve4.1 High Tier
Resolution
1080P ( 1920 × 1080 ), 720P ( 1280 × 720 ), D1, CIF, 480 × 240
Main Stream (S1)
1080P / 720P @30fps
Sub Stream (S2)
D1 / CIF / 480 × 240 @ 30fps
Third Stream (S3)
Bit Rate
64 Kbps ~ 5 Mbps
Bit Rate Type
VBR / CBR
Image Settings
ROI, Saturation, Brightness,Chroma,Contrast,Wide Dynamic, Sharpen,NR,…etc. adjustable through client software or web browser
ROI
Support ROI coding, each ROI to be configured separately
· AUDIO
Audio Compression
G711A / U
Two-way audio
· STORAGE
SD card
Built-in micro SD card slot; up to 128GB
Network remote storage
Yes
Hardware Reset
Yes
· FUNCTIONS
Remote Monitoring
Web browsing,CMS remote control
Online Connection
Support simultaneous monitoring for up to 3 users Support multi-stream real time transmission
Network Protocol
UDP, IPv4, IPv6,DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP, SNMP,802.1x, UPnP, HTTPs, QoS
Interface Protocol
ONVIF
Smart Alarm
Motion detection; SD card full; SD card error
Intelligent Analytics
Exception, Line Crossing, Intrusion
General function
Watermark, IP address filtering, video mask, heartbeat, password protection
PoEYes
· OTHERS
Power Supply
DC12V / PoE
Power Consumption
<5.5 W
Operating Environment
– 30 °C ~ 60 °C (-22°F~140°F)
Humidity: less than 95 % (non-condensing)
Dimensions
Φ 94.6 × 82.8 mm
Weight
Approx. 450g
Installation
Ceiling mounting (wall mounting available with the junction box and bracket)
Ingres Protection
IP67
